| Engine Model |
Kohler KDI 1903TCR or JCB EcoMAX Turbo Diesel |
| Gross Engine Horsepower |
74 hp (55 kW) at 2,400 RPM |
| Rated Operating Capacity |
2,700 lbs (1,225 kg) at 50% tipping load |
| Operating Weight |
8,225 lbs (3,730 kg) |
| Travel Speed |
Up to 7.3 mph (11.8 km/h) |
| Loader Lift Capacity |
3,000 lbs (1,360 kg) |
| Loader Breakout Force |
8,500 lbs (3,855 kg) |
| Max Dump Height |
8 ft 2 in (2,500 mm) |
| Auxiliary Hydraulic Flow |
24.2 gpm (91.7 L/min) |
| Fuel Tank Capacity |
23.8 gal (90 L) |
| Width Over Tires |
74 in (1,880 mm) |
| Ground Clearance |
8.9 in (227 mm) |
| Hydraulic System Capacity |
10.5 gal (40 L) |
| Height to Top of Cab |
78 in (1,981 mm) |
| Turning Radius |
76 in (1,930 mm) |
