2024 Kubota BX2380 Tractor

2024 Kubota BX2380 Tractor

Feature Specification
Engine Model Kubota D902-E4, 3-cylinder diesel
Engine Type Liquid-cooled, vertical, 4-cycle
Displacement 54.8 cu. in. (898 cc)
Rated Engine Speed 3,000 RPM
Gross Engine Horsepower 23.0 HP (17.2 kW) at 3,000 RPM
PTO Horsepower 18.5 HP (13.8 kW) at 3,000 RPM
Fuel Tank Capacity 6.6 gal (25 liters)
Transmission Type Hydrostatic Transmission (HST)
Drive Type 4WD (Four-Wheel Drive)
PTO Type Independent, live
Rear PTO Speed 540 RPM
Hydraulic System Type Dual pump system
Hydraulic Pump Output 5.7 gpm (21.6 L/min)
3-Point Hitch Category I
Lift Capacity at 24″ Behind Pin 680 lbs (310 kg)
Steering Type Hydrostatic power steering
Overall Length (with 3-Point Hitch) 94.1 in. (2,388 mm)
Overall Width (minimum tread) 45.3 in. (1,151 mm)
Overall Height (with ROPS) 88.6 in. (2,250 mm)
Wheelbase 53.1 in. (1,350 mm)
Ground Clearance 6.6 in. (168 mm)
Weight (with mower) 1,430 lbs (649 kg)
Front Tires 18×8.50-10
Rear Tires 26×12.00-12
Traveling Speed (Forward) 0 to 8.1 mph (0 to 13 km/h)
Traveling Speed (Reverse) 0 to 6.0 mph (0 to 9.6 km/h)
Turning Radius 6.1 ft (1.85 m) without brake
Mower Deck Options 48″, 54″, or 60″ mid-mount mower decks
Loader Compatibility LA344 Front Loader
Lift Capacity (at Full Height) 750 lbs (340 kg)
